Overview

　　The Guanshengtai Torque Testing Machine is a specialized device designed for the precise testing of torque performance in various rotating components, fasteners, and screw-in products. Utilizing a high-precision torque sensor, servo loading system, and precision fixtures, the machine can automatically or semi-automatically measure the starting torque, maximum torque, dynamic torque, static torque, and rotation angle of a product. The torque measurement range covers 0.1-100 N·m, with a measurement accuracy of ±0.5%FS, meeting the torque quality control requirements of various products.

　　Technical parameters:

　　Model Number: GST-WJ020A

　　Sizes:L300*W380*H974(MM)

　　POWER:1KW

　　VOLTAGE:220V

　　WEIGHT:60KG

　　ACCESSORIES:Linear module

　　Customized Support: Yes

　　Core Advantages:

　　High-Precision Measurement: Employing a high-sensitivity strain gauge torque sensor and a high-precision data acquisition module, it captures minute changes in torque values in real time, providing accurate and reliable measurement data. It can precisely measure multiple parameters such as starting torque, maximum torque, breaking torque, and rotation angle.

　　Multi-Mode Testing Function: Supports multiple testing modes including real-time display of torque-angle curves, peak hold, constant torque detection, and constant angle detection, meeting the torque testing needs of different products (threaded connectors, screw caps, rotary switches, torsion springs, etc.).

　　Automatic Loading and Precise Control: Utilizes a servo motor-driven loading mechanism with steplessly adjustable loading speed (0.1-30 r/min), simulating actual stress conditions during manual tightening or automated assembly. Testing conditions are reproducible and traceable.

　　Data Storage and Traceability: Built-in large-capacity storage automatically saves test data and allows export to USB flash drives or the factory's MES system. Supports multi-dimensional traceability queries by batch, date, operator, etc., meeting the recording and traceability requirements of ISO, GMP, and other quality management systems.

　　Multi-Specification Flexible Compatibility: Equipped with quick-change clamping fixtures, it can adapt to products of various shapes, including round, square, and irregular shapes. The testing range covers micro screws (M1.0) to large caps (100mm in diameter), allowing for flexible and convenient product changeovers.

　　Safety Protection Functions: Equipped with multiple safety mechanisms including overload protection, emergency stop, and limit protection. Automatic unloading and alarm when torque exceeds the limit prevent damage to the sensor and the tested product.

　　Easy Operation: Employs a PLC and touchscreen human-machine interface. Parameter settings are intuitive, and the testing process displays real-time curves, providing clear and concise test data. Supports storage of multiple product parameter formulas, allowing for one-click recall during production changes.

　　Applicable Scenarios: Widely applicable to torque performance testing and quality control in consumer goods manufacturing (cosmetic bottle caps, daily chemical pump heads, pharmaceutical bottle cap tightening torque testing), automotive parts (screw tightening torque, steering system torque testing), electronic products (rotary switches, potentiometer rotation torque), hardware products (threaded fasteners, valve tightening torque), and medical devices (syringe tightening, surgical instrument joint torque). Guanshengtai torque testing machines, with their high-precision and high-reliability torque measurement performance, help manufacturing enterprises achieve standardized control of key torque parameters, safeguarding product quality.
